IVECO DAILY 4X4 (2014-PRESENT) AD-BLUE MODELS

110 LITRE REPLACEMENT LONG RANGE FUEL TANK

This system is designed to pump the fuel from the Brown Davis auxiliary fuel tank into the vehicles standard fuel tank. At the flick of a switch, fuel will replenish your vehicles standard tank, which in turn is then fed to the engine. An LED gauge is supplied to show the driver the fuel level of the auxiliary fuel tank at all times. When the auxiliary tank becomes empty an automatic alarm will sound to alert the driver to switch the pump system off. This prevents the pump from continuously running, preventing fuel pump failure. All parts and hardware for installation are supplied.

Specifications



PART NUMBER: IVD4SCA3 (SINGLE CAB) IVD4DCA4 (DUAL CAB)
TANK TYPE: TRANSFER AUXILIARY
CAPACITY: 110 LITRES
FILLER POINT: PASSENGER SIDE BEHIND CABIN (FILLER SUPPLIED)
FUEL SUPPLY METHOD: TRANSFERS TO MAIN TANK
TANK LOCATION: UNDER MIDDLE
FITTING TIME: 5 hour/s
MODIFICATIONS: NONE REQUIRED
COMMENTS: FITS WITH SPARE WHEEL



Key features of the Ford Everest Replacement Long Range Fuel Tank

1
2
3
4
5
6
7
1

Internal baffling system to prevent fuel slosh and strengthen tank structure

2

Gusseted brackets with double thickness pads to spread tank mounting loads

3

Fuel sender unit- fuel level float

4

Filler point- connects to supplied filler

5

Fast fill breather for rapid filling and to reduce bowser shut off (works with fast fill)

6

Drain plug- for draining bad fuel

7

Fuel pick-up- pumps fuel to vehicles main tank

Fuel Tank Capacity / Driving Range



APPROX FIGURES ONLY– FROM CARADVICE.COM.AU



15 LITRES PER 100KM

  • –
    –
  • 90 Litre Standard Tank
  • 90LT Standard Tank + 110 Litre Brown Davis Long Range Fuel Tank
  • Fuel Consumption
    8.4LT/100km
  • 600km
  • 1333.33km
  • Percentage Increase
    Brown Davis Long Range Fuel Tank
  • 90 Litre Standard Tank
  • 122.22% Increase in Capacity

Whilst every effort has been made to ensure these figures are accurate vehicles may vary. Vehicles should never be pushed to the point of running out of fuel as it may harm your vehicles engine.

122.22% INCREASE IN FUEL CAPACITY

Step by Step DIY instructions supplied

The Brown Davis Iveco 4×4 auxiliary tank comes with instructions but is still advice to get fitted by approved dealer- Wiring and fuel plumbing knowledge required

Compatiblity with other products

  • Suspension

    Room allowed to fit with aftermarket suspension

  • Exhuasts

    Room allowed to fit with aftermarket exhausts that follow standard route

Warranty and Surport

3 YEAR WARRANTY

For total peace of mind Brown Davis offers a 3 year warranty on all its fuel tanks. With an Australia wide network built over the 30+ years in the industry, you can go away on your longest journey knowing you will have full support with any issues.

Brown Davis Long Range Fuel Tanks

Taking people around Australia since 1978
